178488-11N Rectangular Connector Header 5 Pin High Current Connector

Name: 17848811N Rectangular Connector Header 5 Pin High Current Connector
Brand: Jovelix
Price: 10 USD

Quality 178488-11N Rectangular Connector Header 5 Pin High Current Connector for sale

Model Number : 178488-11N

Sealing : The plug connector complies with the MIL-DTL-38999M requirements for low-pressure impregnation.

Salt spray resistance : W class:500h K, TA Class:1000h; F Class:48h/96h; FT Class:96h

Delivery Time : 2-9weeks

Packaging Details : standard export package

MOQ : 10pcs

Supply Ability : 10000pcs per month

Payment Terms : L/C,T/T,Western Union

Certification : AS9001

Dampness and Heat : According to MIL-DTL-38999M:24 hours 10 cycles

Temperature range : W Class:-65 ° C to +175 ° C F, K, FT, TA categories:-65 °C to +200 °C

Price : 10$-500$

Brand Name : Jovelix

Place of Origin : China

Liquid resistance : Resistant to various fuels, coolant, and solvents

Contact Now

J1784/18-N Model Naming

178488-11N Rectangular Connector Header 5 Pin High Current Connector

The connector rear cable clamp and shielding accessory is used to fasten the shielding braid and secure the cable body to the connector rear assembly. It ensures proper electrical connection between the cable shielding mesh and rear accessories, providing reliable electromagnetic shielding and environmental protection.

This accessory is available in various lengths and is suitable for extended-length cable assembly applications, including high-frequency and low-frequency mixed installations. Pre-assembled cables are recommended to ensure stable performance, reliable installation, and consistent shielding effectiveness.

Table 1

Shell Number	For each housing number, the wire diameter specification can be selected.	D1	Thread D2
09	01~02	16.5	M12*1.0
11	01~03	19.5	M15*1.0
13	02~04	22.5	M18*1.0
15	02~05	26.5	M22*1.0
17	02~06	29.5	M25*1.0
19	03~07	32.5	M28*1.0
21	03~08	36.0	M31*1.0
23	03~09	38.5	M34*1.0
25	04~10	41.7	M37*1.0

Table 2

Line diameter specification number	Adaptive cable diameter range C
01	1.57~3.18
02	3.18~6.35
03	6.35~9.53
04	9.53~12.7
05	12.7~15.88
06	15.88~19.05
07	19.05~22.23
08	22.23~25.4
09	25.4~28.58
10	28.58~31.75

Table 3

Shell Number	RLE	L
09~25	Standard (omitted)	64.1
09~25	A	88.1
15~25	B	113.5
21~25	C	138.9

Straight Accessories(J1784/88 or JY599II-FJA00)

178488-11N Rectangular Connector Header 5 Pin High Current Connector

Shell Size	D1	Thread D2	A(02 Cable Exit Holes)	A(03 Cable Exit Holes)
09	17.6	M12*1.0	N/A	6.4
11	20.6	M15*1.0	N/A	7.9
13	23.6	M18*1.0	7.9	11.1
15	27.6	M22*1.0	11.1	14.3
17	30.3	M25*1.0	12.7	15.9
19	33.3	M28*1.0	15.9	19.1
21	36.8	M31*1.0	15.9	20.6
23	39.3	M34*1.0	17.5	23.8
25	42.3	M37*1.0	19.1	25.4
